FUNCTIONS
The
3314A
outputs
Sine, Square and Triangle
functions
and Arbitrary
waveforms
(see ARB)
with
a related signal
from
the
SYNC
output.
When functions are
Off,
only DC
Offset
remains.
Operating
Characteristics
These operating characteristics apply to all functions.
Frequency Range
001
Hz to
19.99MHz
.001
Hz
to
1MHz,
Opt
001
Amplitude
Range 01 mVp-p
to
t Ovp-p
.03mVpwp
to
30Vp-p,
Opt
001
Variable
Symmetry
5%
to
95%,
Freq <
2MHz
DC
Offset
± 5VDC, independent
of
Ampl
± 15VDC, Opt
001
Invert
Functions AC component is inverted,
DC component
not
affected
Function OFF AC component = Ovp-p,
DC component
not
affected
HlVtlrsiH. The Haversine
function
is a special sub-set
of
the Sine function
which
is
especially suited
to
driving mechanical systems. To
output
a Haversine, set the
3314A
controls as
shown
:
Mode
N CYCLE
N 1
Frequency sets the period
of
each Haversine
Trigger . . . . . . . . . . . . . . . . . , . Internal
SWITR INTVL ", , ,
..
sets repetition rate of individual Haversines
Phase , ". . , -90degrees
Symmetry
, changes ratio of rising
to
falling time
without
affecting the period
Offset
, "
1/2
of AMPTD
(-1/2
of
AMPTD
if
+90°)
60
