HP 3314A Operating Manual

FREE RUN (Log Sweeps)
1 6. Sweeping a Low Pass Filter
!
I
i ~
.
,
PRESET
AMPLITUDE
... . . . .• , .. ' " .. ". , ... . , 1OVp-p
SWEEP INTERVAL ... • .• ,.". " " 40ms/DECADE
START FREQUENCY , , , , . . . . . . . . . .
510H2:
STOP FREQUENCy , , , " . . 5.1MH2:
MARKER FREQUENCY • . •.. . . .. , ., ., . . , 809kHz
SWEEP TYPE . . . , . , , • , • , . . , .. . . , .. . .. , " Log
PR
AP10VO T140MS ST510HZ SP5.1MZ MK809KZ
SW2
Note: The X Axis control voltage is from the3314A's X
Axis
output . Note the Intensifi cation every decade end at
the Marker Frequency,
1 7. 1 Decade Sweep
PRESET
AMPLITUDE
., . . , , , . . , . . . 10Vp-p
SWEEP INTERVAL , . . . • , , 50ms/DECADE
START FREQUENCY . . , . . . . . • .
.• • . . . .. 1999kHz
STOP FREQUENCY . ', __ , , . , 19.99MHz
MARKER FREQUENCY •. . . . . . . . . . . . , . . . . ,OMH2:
SWEEP TYPE , ' . . . . . • . . . . . . , , . . Log
PR
AP10VO TI50MS ST1999KZ SP19.99MZ MK10MZ
SW2
18. Audio Sweep (20Hz to 20kHz)
PRESET
AMPLITUDE
•.. , • . .. . , . " , . , " " . 1OVp-p
SWEEP INTERVAL
40ms /DECADE
START FREQUENCY
20H2:
STOP FREQUENCY . , . . . . • . . • • . • . . . . . . . . 20kHz
MARKER FREQUENCY , , 1
kH2:
SWEEP TYPE ... . •. •• . . . . ... .. .. . . . .. . .. Log
PR
AP10VO TI40MS ST20HZ SP20KZ MK1KZ SW2
19. Sub-Audio Sweep (2Hz to 20Hz)
.~ I
I
PRESET
AMPLITUDE , . . .
•. . .. . , .. , . . , " . . . 1OVp-p
SWEEP INTERVAL h/DECADE
START FREQUENCY . . . . . .. .. .. .. •. . .. . . . . 2Hz
STOP FREQUENCY . . . . . . . . . . . • . . . . . . . . . . 20Hz
MARKER FREQUENCY 13Hz
SWEEP TYPE Log
PR AP10VO
TllSN ST2HZ SP20HZ MK13HZ SW2
20. Low Frequency Sweep (.2Hz to 2Hz)
PRESET
AMPLITUDE , . . . . .
.. 10Vp-p
SWEEP INTERVAL , . .. . . . . ...•. . . . . , 5a/DECADE
START FREQUENCY , . . , 2Hz
STOP FREQUENCY , , . . . . . . . . . . . . . . . . . . . . . 2Hz
MARKER FREQUENCY . , , 935Hz
SWEEP TYPE , . . . . . . . . . . . . . . Log
PR
AP10VO TI5SN ST .2HZ SP2HZ MK.935HZ SW2
26
l\ 1\ , ~,
- I\: t I,
\
f 'I " , t , .. ' 1
t II I -\ 1 I
. t t j I
,
:,'V:'
~. ! I
V \;' :j~:
i.
,
, I I
