HP Compaq dx2400 User Manual

HP highly recommends that you create a Recovery Disc Set immediately before
using the computer and schedule regular automatic Recovery Point backups.
To create the Recovery Disc Set:
1. Click Start > HP Backup and Recovery > HP Backup and Recovery
Manager to open the Backup and Recovery Wizard, then click Next.
2. Select Create a set of recovery discs (Recommended) and click Next.
3. Follow the instructions in the wizard.
For more information on using HP Backup and Recovery Manager, refer to the
HP Backup and Recovery Manager User Guide by selecting Start > HP Backup
and Recovery > HP Backup and Recovery Manager Manual.
NOTE: You can order a Recovery Disc Set from HP by calling the HP support
center. Go to the following Web site, select your region, and click the Technical
support after you buy link under the Call HP heading to obtain the support center
telephone number for your region.
http://welcome.hp.com/country/us/en/wwcontact_us.html
HP Insight Diagnostics
NOTE: HP Insight Diagnostics is included with some computer models only.
The HP Insight Diagnostics utility allows you to view information about the hardware
configuration of the computer and perform hardware diagnostic tests on the
subsystems of the computer. The utility simplifies the process of effectively
identifying, diagnosing, and isolating hardware issues.
The Survey tab is displayed when you invoke HP Insight Diagnostics. This tab
shows the current configuration of the computer. From the Survey tab, there is
access to several categories of information about the computer. Other tabs provide
additional information, including diagnostic test options and test results. The
information in each screen of the utility can be saved as an html file and stored on
a diskette or USB HP Drive Key.
Use HP Insight Diagnostics to determine if all the devices installed on the computer
are recognized by the system and functioning properly. Running tests is optional
but recommended after installing or connecting a new device.
You should run tests, save the test results, and print them so that you have printed
reports available before placing a call to the Customer Support Center.
NOTE: Third party devices may not be detected by HP Insight Diagnostics.
Accessing HP Insight Diagnostics
To access HP Insight Diagnostics, you must create a Recovery Disc Set then boot
to the CD containing the utility. It can also be downloaded from
http://www.hp.com. See Downloading the Latest Version of HP Insight Diagnostics
on page 4 for more information.
ENWW
HP Insight Diagnostics
3

HP Compaq dx2400 Specifications

General

Tcase	74.1 °C
Bus type	FSB
Stepping	M0
Processor cache	2 MB
Processor cores	2
Processor model	E5200
System bus rate	- GT/s
Processor family	Intel® Pentium®
Processor series	Intel Pentium E5000 Series for Desktop
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	82 mm²
Processor frequency	2.5 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	12.5
Number of Processing Die Transistors	228 M
Audio system	HD
Product type	PC
Motherboard chipset	Intel® G33
Memory slots	4x DIMM
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	- GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	DVD Super Multi
Total storage capacity	250 GB
LightScribe	Yes
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Discrete graphics card model	Intel® GMA 3100
Operating system installed	Windows Vista Business
Compatible operating systems	Windows XP Windows Vista
Optional operating system supplied	Windows XP Professional
Serial ports quantity	-
USB 2.0 ports quantity	6
Firewire (IEEE 1394) ports	0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black, Silver
Country of origin	China
Cable lock slot type	Kensington
Number of 3.5\" bays	3
Non-operating altitude	0 - 9144 m
Operating temperature (T-T)	10 - 35 °C
Power supply input voltage	90 - 240 V
Power consumption (typical)	300 W
Power supply input frequency	50 - 60 Hz
Processor ARK ID	37212
Processor package size	37.5 x 37.5 mm

Weight and Dimensions

Depth	373 mm
Width	180 mm
Height	365 mm
Weight	10200 g
