Helpful Hints
If you encounter problems with the computer, monitor, or software, see the following
list of general suggestions before taking further action:
●
Check that the computer and monitor are plugged into a working electrical
outlet.
●
Check to see that the voltage select switch (some models) is set to the
appropriate voltage for your region (115V or 230V).
●
Check to see that the computer is turned on and the green power light is on.
●
Check to see that the monitor is turned on and the green monitor light is on.
●
Check the Power LED on the front of the computer to see if it is flashing. The
flashing lights are error codes that will help you diagnose the problem. Refer
to
Interpreting POST Diagnostic Front Panel LEDs and Audible Codes
on page 14 in this guide for details.
●
Turn up the brightness and contrast controls of the monitor if the monitor is
dim.
●
Press and hold any key. If the system beeps, then the keyboard should be
operating correctly.
●
Check all cable connections for loose connections or incorrect connections.
●
Wake the computer by pressing any key on the keyboard or pressing the power
button. If the system remains in suspend mode, shut down the computer by
pressing and holding the power button for at least four seconds. Then press
the power button again to restart the computer. If the system will not shut down,
unplug the power cord, wait a few seconds, then plug it in again. The computer
will restart if automatic start on power loss is set in Computer Setup. If it does
not restart, press the power button to start the computer.
●
Reconfigure your computer after installing a non–plug and play expansion
board or other option. See
Solving Hardware Installation Problems
on page 12 for instructions.
●
Be sure that all the needed device drivers have been installed. For example,
if you are using a printer, you need a driver for that model printer.
●
Remove all bootable media (diskette, CD, or USB device) from the system
before turning it on.
●
If you have installed an operating system other than the factory-installed
operating system, check to be sure that it is supported on the system.
●
If the system has multiple video sources (embedded, PCI, or PCI-Express
adapters) installed (embedded video on some models only) and a single
monitor, the monitor must be plugged into the monitor connector on the source
selected as the primary VGA adapter. During boot, the other monitor
connectors are disabled and if the monitor is connected into these ports, the
monitor will not function. You can select which source will be the default VGA
source in Computer Setup.
8 Quick Setup & Getting Started ENWW

HP Compaq dx2400 Specifications

General

Tcase	74.1 °C
Bus type	FSB
Stepping	M0
Processor cache	2 MB
Processor cores	2
Processor model	E5200
System bus rate	- GT/s
Processor family	Intel® Pentium®
Processor series	Intel Pentium E5000 Series for Desktop
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	82 mm²
Processor frequency	2.5 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	12.5
Number of Processing Die Transistors	228 M
Audio system	HD
Product type	PC
Motherboard chipset	Intel® G33
Memory slots	4x DIMM
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	- GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	DVD Super Multi
Total storage capacity	250 GB
LightScribe	Yes
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Discrete graphics card model	Intel® GMA 3100
Operating system installed	Windows Vista Business
Compatible operating systems	Windows XP Windows Vista
Optional operating system supplied	Windows XP Professional
Serial ports quantity	-
USB 2.0 ports quantity	6
Firewire (IEEE 1394) ports	0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black, Silver
Country of origin	China
Cable lock slot type	Kensington
Number of 3.5\" bays	3
Non-operating altitude	0 - 9144 m
Operating temperature (T-T)	10 - 35 °C
Power supply input voltage	90 - 240 V
Power consumption (typical)	300 W
Power supply input frequency	50 - 60 Hz
Processor ARK ID	37212
Processor package size	37.5 x 37.5 mm

Weight and Dimensions

Depth	373 mm
Width	180 mm
Height	365 mm
Weight	10200 g
