HP Compaq dx2400 User Manual

Accessing the User Guides
HP user guides and HP Insight Diagnostics are available on the hard drive (some
models) and are also available at
http://www.hp.com/support.
To access HP user guides:
▲
Select Start > All Programs > HP User Manuals.
To access HP Insight Diagnostics:
▲
Refer to Accessing HP Insight Diagnostics in this guide.
To access the HP Backup and Recovery Manager User Guide:
▲
Select Start > HP Backup and Recovery > HP Backup and Recovery
Manager Manual.
To access the Safety and Comfort Guide:
▲
Select Start > All Programs > HP Safety and Comfort Guide.
The menu and books are displayed in the language chosen during initial system
setup or as specified later in the Windows Regional Settings. If the Regional
Settings do not match one of the supported languages, the menu and books are
displayed in English.
Before You Call for Technical Support
If you are having problems with the computer, try the appropriate solutions below
to try to isolate the exact problem before calling for technical support.
●
Run the diagnostics utility. Refer to the Troubleshooting Guide for more
information.
●
Run the Drive Protection System (DPS) Self-Test in Computer Setup. Refer
to the Computer Setup (F10) Utility Guide for more information.
NOTE: The Drive Protection System (DPS) Self-Test software is available on
some models only.
●
Check the power LED on the front of the computer to see if it is flashing red.
The flashing lights are error codes that will help you diagnose the problem.
Refer to
Interpreting POST Diagnostic Front Panel LEDs and Audible Codes
on page 14 in this guide for details.
●
If the screen is blank, plug the monitor into a different video port on the
computer if one is available. Or, change out the monitor with a monitor that
you know is functioning properly.
●
If you are working on a network, plug another computer with a different cable
into the network connection. There may be a problem with the network plug
or cable.
●
If you recently added new hardware, remove the hardware and see if the
computer functions properly.
6 Quick Setup & Getting Started ENWW

HP Compaq dx2400 Specifications

General

Tcase	74.1 °C
Bus type	FSB
Stepping	M0
Processor cache	2 MB
Processor cores	2
Processor model	E5200
System bus rate	- GT/s
Processor family	Intel® Pentium®
Processor series	Intel Pentium E5000 Series for Desktop
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	82 mm²
Processor frequency	2.5 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	12.5
Number of Processing Die Transistors	228 M
Audio system	HD
Product type	PC
Motherboard chipset	Intel® G33
Memory slots	4x DIMM
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	- GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	DVD Super Multi
Total storage capacity	250 GB
LightScribe	Yes
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Discrete graphics card model	Intel® GMA 3100
Operating system installed	Windows Vista Business
Compatible operating systems	Windows XP Windows Vista
Optional operating system supplied	Windows XP Professional
Serial ports quantity	-
USB 2.0 ports quantity	6
Firewire (IEEE 1394) ports	0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black, Silver
Country of origin	China
Cable lock slot type	Kensington
Number of 3.5\" bays	3
Non-operating altitude	0 - 9144 m
Operating temperature (T-T)	10 - 35 °C
Power supply input voltage	90 - 240 V
Power consumption (typical)	300 W
Power supply input frequency	50 - 60 Hz
Processor ARK ID	37212
Processor package size	37.5 x 37.5 mm

Weight and Dimensions

Depth	373 mm
Width	180 mm
Height	365 mm
Weight	10200 g
