NOTE: HP Insight Diagnostics is included as part of the Recovery Disk Set with
some computer models only.
If you have already created a Recovery Disc Set, begin the following procedure at
step 4.
1. Click Start > HP Backup and Recovery > HP Backup and Recovery
Manager to open the Backup and Recovery Wizard, then click Next.
2. Select Create a set of recovery discs (Recommended) and click Next.
3. Follow the instructions in the wizard to create a Recovery Disc Set.
4. Use Windows Explorer to search the Recovery Disc Set for the CD with the
compaq\hpdiags directory.
5. While the computer is on, insert the CD into an optical drive on the computer.
6. Shut down the operating system and turn off the computer.
7. Turn on the computer. The system will boot to the CD.
NOTE: If the system does not boot to the CD in the optical drive, you may
need to change the boot order in the Computer Setup (F10) utility so that the
system attempts to boot to the optical drive before booting to the hard drive.
Refer to the Computer Setup (F10) Utility Guide for more information.
8. Select the appropriate language and click Continue.
NOTE: It is recommended that you accept the assigned default keyboard for
your language unless you want to test your specific keyboard.
9. In the End User License Agreement page, click Agree if you agree with the
terms. The HP Insight Diagnostics utility launches with the Survey tab
displayed.
Downloading the Latest Version of HP Insight Diagnostics
1. Go to http://www.hp.com.
2. Click the Software & Driver Downloads link.
3. Enter your product number (for example, dc7700) in the text box and press
the Enter key.
4. Select your specific computer model.
5. Select your OS.
6. Click the Diagnostic link.
7. Click HP Insight Diagnostics Offline Edition.
8. Select a language and click Download.
4 Quick Setup & Getting Started ENWW

HP Compaq dx2400 Specifications

General

Tcase	74.1 °C
Bus type	FSB
Stepping	M0
Processor cache	2 MB
Processor cores	2
Processor model	E5200
System bus rate	- GT/s
Processor family	Intel® Pentium®
Processor series	Intel Pentium E5000 Series for Desktop
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	82 mm²
Processor frequency	2.5 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	12.5
Number of Processing Die Transistors	228 M
Audio system	HD
Product type	PC
Motherboard chipset	Intel® G33
Memory slots	4x DIMM
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	- GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	DVD Super Multi
Total storage capacity	250 GB
LightScribe	Yes
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Discrete graphics card model	Intel® GMA 3100
Operating system installed	Windows Vista Business
Compatible operating systems	Windows XP Windows Vista
Optional operating system supplied	Windows XP Professional
Serial ports quantity	-
USB 2.0 ports quantity	6
Firewire (IEEE 1394) ports	0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black, Silver
Country of origin	China
Cable lock slot type	Kensington
Number of 3.5\" bays	3
Non-operating altitude	0 - 9144 m
Operating temperature (T-T)	10 - 35 °C
Power supply input voltage	90 - 240 V
Power consumption (typical)	300 W
Power supply input frequency	50 - 60 Hz
Processor ARK ID	37212
Processor package size	37.5 x 37.5 mm

Weight and Dimensions

Depth	373 mm
Width	180 mm
Height	365 mm
Weight	10200 g
