Reverse this procedure to install the speakers.
Solid-state drive
To remove the solid-state drive, use this procedure and illustration.
Table 5-4
Solid-state drive description and part numbers
Description Spare part number
M.2 2280, PCIe-NVMe:
1 TB value solid-state drive L85370-005
512 GB value solid-state drive L85364-005
256 GB value solid-state drive L85354-005
Before removing the solid-state drive, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 29).
2. Remove the bottom cover (see Bottom cover on page 29).
3. Disconnect the battery cable from the system board (see Battery on page 31).
Remove the solid-state drive:
1. Remove the Phillips M2.0 × 2.9 screw (1) that secures the solid-state drive shield to the computer.
2. Detach the grounding tape (2) that secures the solid-state drive shield to the memory module shield.
3. Remove the solid-state drive shield (3).
The solid-state drive shield is not available as a spare part component.
Solid-state drive
33
