HP JD320B Installation Guide

46
Product
code
Description
Central
wavelength
(nm)
Fiber
diamete
r (µm)
Multimode fiber
modal
bandwidth
(MHz*km)
Maximum
transmission
distance
JD324A
HP A3600 Switch SFP
Stacking Kit
N/A
UTP/STP
N/A
1.5 m (4.92 ft)
Table 18 100-Mbps SFP transceiver module specifications
Product
code
Description
Central
wavelength
(nm)
Fiber diameter
(µm)
Maximum
transmission
distance
JD102B
HP X110 100M SFP LC FX
Transceiver
1310
50/125
2 km (1.24 miles)
62.5/125
JD120B
HP X110 100M SFP LC LX
Transceiver
1310
9/125
15 km (9.32 miles)
JD100A
HP X115
100M SFP
LC BX 10-U
Transceiver
The two
modules
must be
used
together.
TX: 1310
RX: 1550
9/125
15 km (9.32 miles)
JD101A
HP X115
100M SFP
LC BX 10-D
Transceiver
TX: 1550
RX: 1310
9/125
15 km (9.32 miles)
NOTE:
 To guarantee the functionality of the SFP ports, always use HP SFP transceiver modules on the A3100 v2
Switch Series.
 The SFP transceiver modules available for this switch series are subject to change over time. For the most
up-to-date list of SFP transceiver modules, consult your HP sales representative or technical support
engineer.
 For the SFP transceiver module specifications, see HP A-Series Switches Transceiver Modules User
Guide .
 For how to install or replace an SFP transceiver module, see Pluggable SFP/SFP+/XFP Transceiver
Modules Installation Guide .
LEDs
Table 19 LEDs at a glance
Switch series
LED
Non PoE switches
Power LED (page 47)
10/100Base-TX Ethernet port LEDs (page 47)
Combo interface LEDs (page 47)
PoE switches
Power LED (page 48)
