24 Getting Started Guide
Using the Memory Card Reader
NOTE: CompactFlash and Microdrive are keyed and cannot be inserted
incorrectly. Insert the receptacle edge (holes) of this media into the slot.
For the two-slot reader, the Secure Digital (SD) card, the MultiMediaCard (MMC),
and the Memory Stick (MS or MS-Pro) cards must be inserted upside down (gold
connector fingers facing up). Note the direction of the notched corner on the
media.
1 Insert the media into the card slot until it stops. The in-use light (A) on the card
reader lights, and the PC automatically detects the media.
2 The PC opens a window so you can use the media contents. You can copy files
from or to the media.
3 When you are finished, right-click the drive icon, select Eject, check that the in-
use light is on but not blinking, and then remove the media. A steady light
indicates that the PC is not reading or writing the media.
WARNING: Do not try to remove media when the In-use light is
blinking. Doing so may cause loss of data.
4-Slot Memory Card Reader
A
E
D
B
C
Card Insert Into 4-slot reader
CompactFlash Type I media Receptacle edge (holes) C (lower-left)
CompactFlash Type II media Receptacle edge (holes) C (lower-left)
IBM Microdrive disk drive Receptacle edge (holes) C (lower-left)
Secure Digital (SD)
Memory Card
Facing up D (upper-right)
MultiMediaCard (MMC) Facing up D (upper-right)
Memory Stick (MS)
Memory Card
Facing up E (lower-right)
Memory Stick (MS-PRO)
Memory Card
Facing up E (lower-right)
SmartMedia (SM)
Memory Card
Facing up B (upper-left)
xD media Facing up B (upper-left)
A In-use light
B Upper-left slot
C Lower-left slot
D Upper-right slot
E Lower-right slot
