HP PROCURVE 2910AL User Manual

Configuring Advanced Threat Protection
Using the Instrumentation Monitor
Viewing the Current Instrumentation Monitor
Configuration
The show instrumentation monitor configuration command displays the config-
ured thresholds for monitored parameters.
ProCurve# show instrumentation monitor configuration
PARAMETER LIMIT
------------------------- -------------- -
mac-address-count 1000 (med)
ip-address-count 1000 (med)
system-resource-usage 50 (med)
system-delay 5 (high)
mac-moves/min 100 (med)
learn-discards/min 100 (med)
ip-port-scans/min 10 (med)
arp-requests/min 100 (low)
login-failures/min 10 (med)
port-auth-failures/min 10 (med)
SNMP trap generation for alerts: enabled
Instrumentation monitoring log : enabled
Figure 10-15.Viewing the Instrumentation Monitor Configuration
An alternate method of determining the current Instrumentation Monitor
configuration is to use the show run command. However, the show run
command output does not display the threshold values for each limit set.
10-27

HP PROCURVE 2910AL Specifications

General

Model	HP ProCurve 2910al
Switching Capacity	128 Gbps
Throughput	95.2 Mpps
Management	Web, CLI, SNMP
Jumbo Frame Support	Yes
Manageable	Yes
Power	100-240 VAC
Power Supply	Internal
Operating Temperature	0°C to 45°C (32°F to 113°F)
Stacking	Yes
MAC Address Table Size	32000 entries
Routing Protocol	RIP, OSPF
Features	IPv6, VLAN, QoS, ACLs
Operating Humidity	15% to 95% non-condensing
Uplink Ports	4
Power over Ethernet	Yes (PoE+ models available)
