Configuring Username and Password Security
Saving Security Credentials in a Config File
SNMP Security Credentials
SNMPv1 community names and write-access settings, and SNMPv3
usernames continue to be saved in the running configuration file even when
you enter the include-credentials command.
In addition, the following SNMPv3 security parameters are also saved:
snmpv3 user “<name>" [auth <md5|sha> “<auth-pass>”]
[priv “<priv-pass>"]
where:
<name> is the name of an SNMPv3 management station.
[auth <md5 | sha>] is the (optional) authentication method used for the
management station.
<auth-pass> is the hashed authentication password used with the
configured authentication method.
[priv <priv-pass>] is the (optional) hashed privacy password used by a
privacy protocol to encrypt SNMPv3 messages between the switch and the
station.
The following example shows the additional security credentials for SNMPv3
users that can be saved in a running-config file:
snmpv3 user boris \
auth md5 “9e4cfef901f21cf9d21079debeca453” \
priv “82ca4dc99e782db1a1e914f5d8f16824”
snmpv3 user alan \
auth sha “8db06202b8f293e9bc0c00ac98cf91099708ecdf” \
priv “5bc4313e9fd7c2953aaea9406764fe8bb629a538”
Figure 2-4. Example of Security Credentials Saved in the Running-Config
Although you can enter an SNMPv3 authentication or privacy password in
either clear ASCII text or the SHA-1 hash of the password, the password is
displayed and saved in a configuration file only in hashed format, as shown in
the preceding example.
For more information about the configuration of SNMP security parameters,
refer to the chapter on “Configuring for Network Management Applications”
in the Management and Configuration Guide for your switch.
2-14
