Drives
Description
Hard drive
2 TB, 7200 rpm, 3.5 inch
1 TB, 10000 rpm
1 TB, 7200 rpm, 3.5 inch
1 TB hard drive, hybrid SSD
500 GB, 10000 rpm
500 GB, 7200 rpm, 2.5 inch
500 GB, 7200 rpm, 2.5 inch, self-encrypting (SED)
500 GB, 5400 rpm, 2.5 inch, FIPS
500 GB hard drive, hybrid SSD
256-GB Solid-state Drive (SSD), self-encrypting (SED)
256-GB Solid-state Drive (SSD)
180-GB Solid-state Drive (SSD), MLC
128-GB Solid-state Drive (SSD)
128-GB Solid-state Drive (SSD), self-encrypting (SED)
120-GB Solid-state Drive (SSD), MLC
32-GB Solid-state Drive (SSD), 2.5 inch, MLC
Optical drive
Blu-ray BD-RW SuperMulti XL Drive
DVD±RW drive
DVD-ROM drive
When installing drives, follow these guidelines:
●
The primary Serial ATA (SATA) hard drive must be connected to the dark blue primary SATA connector
on the system board labeled SATA0.
●
Connect a secondary hard drive to the light blue SATA connector on the system board labeled SATA1.
●
Connect an optical drive to the white SATA connector on the system board labeled SATA5.
●
Connect a media card reader USB 3.0 cable with a USB 3.0 to USB 2.0 adapter to the USB 2.0 connector
on the system board labeled MEDIA.
●
The power cable for the drives has two branches coming off the system board connector. The first
branch is a dual-headed cable with the first connector (four-wire) routed to the 3.5-inch optional drive
bay and the second connector (two-wire) routed to the slim optical drive bay. The second branch is a
32 Chapter 4 Removal and replacement procedures: Small Form Factor
