StatusDescriptionItem
N/ADVD-RW drive2
N/AVideo connector3
N/AUSB connectors (2)4
LEDs off = Normal
LEDs amber = Failure
See “Systems Insight Display LEDs and internal health LED
combinations” on page 50 for LED status information.
See below for online spare and mirror LED status.
Systems Insight Display5
Off = No protection
Green = Protection enabled
Amber = Memory failure occurred
Flashing amber = Memory configuration error
Online spare LED6
Off = No protection
Green = Protection enabled
Amber = Memory failure occurred
Flashing amber = Memory configuration error
Mirror LED7
See “SAS and SATA hard drive LED combinations” on page 49 for HDD
LED status descriptions.
Hard disk drive (HDD)
bays
8
N/AQuick release lever9
Blue = Activated
Flashing = System being remotely managed
Off = Deactivated
UID LED button10
Green = Normal
Amber = System degraded
Red = System critical
Internal health LED11
Green = Normal
Amber = Power redundancy failure
Red = Critical power supply failure
External health LED (power
supply)
12
Green = Network link
Flashing = Network link and activity
Off = No link to network. If power is off, view the rear panel RJ-45 LEDs
for status.
NIC 1 link/activity LED13
Green = Network link
Flashing = Network link and activity
Off = No link to network. If power is off, view the rear panel RJ-45 LEDs
for status.
NIC 2 link/activity LED14
HP ProLiant Storage Server 43
