4 Removal and Replacement Procedures
The following sections provide information about disassembling various components of the computer.
Preparing to disassemble the computer
To avoid injury and equipment damage, always complete the following steps in order, when opening the HP
All-in-One.
1. Remove all media from the computer.
2. Shut down the computer.
3. After the system has completely shut down, disconnect the power adapter from the back of the
computer.
4. Disconnect all other attached cables from the back of the computer.
5. Place the computer face down on a soft at surface. HP recommends that you set down a blanket, towel,
or other soft cloth to protect the screen surface from scratches or other damage.
WARNING! Beware of sharp edges inside the chassis.
Stand
Two stands are available for the computer - a xed height stand and an adjustable height stand. The removal
procedure is the same for both stands.
To remove the stand:
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 19).
2. Press the stand release latch.
3. Rotate the stand away from the computer (1).
4. Slide the stand hooks out of the computer (2).
VESA bracket
A VESA mount option is available. A separate VESA bracket and cover install in place of the stand.
Preparing to disassemble the computer 19
