HP ProOne 600 G5 User Manual

Power button board
The power button board is located at the bottom, right of the computer. It is spared with a plastic holder.
To remove the power button board:
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 19).
2. Remove the stand (see Stand on page 19).
3. Remove the rear port cover (see Rear port cover on page 24).
4. Remove the speaker cover (see Speakers on page 43).
5. Disconnect the power button board cable from the system board ZIF connector (1), and then push the
connector end of the cable through the hole (2) that allows the cable to route to the front of the chassis.
6. Locate the power button board under the speaker cover.
7. Remove Phillips screw (1) that secures the power button board to the computer.
Power button board 45

HP ProOne 600 G5 Specifications

General

Processor	Intel Core i3/i5/i7/i9, Intel Pentium, Intel Celeron
RAM	Up to 64 GB DDR4
Storage	Up to 2TB HDD, up to 1TB SSD
Display	21.5" diagonal FHD (1920 x 1080) IPS anti-glare WLED-backlit
Graphics	Intel UHD Graphics 630
Operating System	Windows 10 Pro
Ports	USB 3.1 Gen 1, USB-C, HDMI, DisplayPort, RJ-45, audio jack
Network	Gigabit Ethernet
Chipset	Intel® Q370
Audio	Integrated stereo speakers
Networking	optional Wi-Fi 6, Bluetooth 5.0
Power Supply	up to 89% efficiency
