Setup Field Name Comment Label
The label includes spaces after every four characters. You can enter or ignore these
spaces – their only purpose is to help with data entry. There is a character
limitation of 40 bytes per line. When you reach this limit, go to the next line to
continue data entry. BIOS ignores the spaces and lines.
If you make an error during data entry, the data will not validate, and the computer
asks you to correct your data input.
Build ID The Build ID of the unit. Flexbuild
System board callouts
Sys Bd Label Color Component Sys Bd Label Color Component
CMOS Yellow Reset CMOS HSENSE White Hood sensor
SATA1 Black Optical drive WLAN Black WLAN module
PROCESSOR Black Processor socket COMM_DP Black Option board
CHFAN Black Fan connector SPKR P8 Black Speaker
LVDS White Display connector PB/MR White Power button
CPUFAN White Fan connector SSD Black M.2 SSD drive
BAT Black RTC battery DIMM3 Black Memory module
DPCONV Black Display panel DIMM1 Black Memory module
SATA0 Black Hard drive WCAM White Webcam connector
TOUCH White Touch panel
42 Chapter 4 Removal and Replacement Procedures

HP ProOne 600 G5 Specifications

General

Processor	Intel Core i3/i5/i7/i9, Intel Pentium, Intel Celeron
RAM	Up to 64 GB DDR4
Storage	Up to 2TB HDD, up to 1TB SSD
Display	21.5" diagonal FHD (1920 x 1080) IPS anti-glare WLED-backlit
Graphics	Intel UHD Graphics 630
Operating System	Windows 10 Pro
Ports	USB 3.1 Gen 1, USB-C, HDMI, DisplayPort, RJ-45, audio jack
Network	Gigabit Ethernet
Chipset	Intel® Q370
Audio	Integrated stereo speakers
Networking	optional Wi-Fi 6, Bluetooth 5.0
Power Supply	up to 89% efficiency
