HP ProOne 600 G5 User Manual

Optical drive
The optical drive mounts on the exterior, rear of the computer. It is secured with two screws.
For a list of available optical drives, see Mass storage devices on page 9.
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 19).
2. Remove the rear port cover (see Rear port cover on page 24).
3. Remove the stand (see Stand on page 19).
4. Remove the rear cover (see Rear port cover on page 24).
5. Remove the two Phillips screws (1) that secure the drive to the computer, move the drive back and forth
(2), and then slide the drive away from the connector to remove it (3).
IMPORTANT: Do not lift the drive as you remove it.
Optical drive 27

HP ProOne 600 G5 Specifications

General

Processor	Intel Core i3/i5/i7/i9, Intel Pentium, Intel Celeron
RAM	Up to 64 GB DDR4
Storage	Up to 2TB HDD, up to 1TB SSD
Display	21.5" diagonal FHD (1920 x 1080) IPS anti-glare WLED-backlit
Graphics	Intel UHD Graphics 630
Operating System	Windows 10 Pro
Ports	USB 3.1 Gen 1, USB-C, HDMI, DisplayPort, RJ-45, audio jack
Network	Gigabit Ethernet
Chipset	Intel® Q370
Audio	Integrated stereo speakers
Networking	optional Wi-Fi 6, Bluetooth 5.0
Power Supply	up to 89% efficiency
