Option board
The option board is connected to the bottom, left of the system board. Underneath the board is a connector
that connects to the system board.
For a list of available option boards, see Illustrated parts catalog on page 6.
To remove the option board:
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 19).
2. Remove the stand (see Stand on page 19).
3. Remove the rear port cover (see Rear port cover on page 24).
4. Remove the two Phillips screws (1) that secure the board to the system board.
5. Lift the board up to disengage it from the connector underneath, and then remove the board from the
computer (2).
NOTE: DisplayPort option board shown. HDMI and serial port option boards are also available.
To install the option board, reverse the removal procedures.
34 Chapter 4 Removal and Replacement Procedures

HP ProOne 600 G5 Specifications

General

Processor	Intel Core i3/i5/i7/i9, Intel Pentium, Intel Celeron
RAM	Up to 64 GB DDR4
Storage	Up to 2TB HDD, up to 1TB SSD
Display	21.5" diagonal FHD (1920 x 1080) IPS anti-glare WLED-backlit
Graphics	Intel UHD Graphics 630
Operating System	Windows 10 Pro
Ports	USB 3.1 Gen 1, USB-C, HDMI, DisplayPort, RJ-45, audio jack
Network	Gigabit Ethernet
Chipset	Intel® Q370
Audio	Integrated stereo speakers
Networking	optional Wi-Fi 6, Bluetooth 5.0
Power Supply	up to 89% efficiency
