Attaching the computer to a mounting fixture
You can remove the computer from the stand and install it on a wall, monitor arm, or other mounting
fixture. There is a VESA mount under the computer stand that is used for mounting the computer.
Table 2-1 Computer dimensions (without stand)
Computer dimensions (without stand)
Height 367.4 mm 14.5 in
Width 521.9 mm 20.5 in
Depth 63.8 mm 2.5 in
Computer weight (without stand)
Minimum configuration 6.63 kg 14.6 lb
With Options 7.88 kg 17.4 lb
VESA standard hole patterns
height x width 100 mm x 100 mm 3.94 in x 3.94 in
Figure 2-10 VESA mounting holes
Attaching the computer to a mounting fixture
17
