Installing 2.5-inch hard disc drives
1. Insert the 2.5-inch hard disc drive or drives into the 2.5-inch disc drive adapter. Be sure that the
connectors are at the opening of the adapter.
NOTE: The primary drive is the lower position in the drive adapter. If only one drive is to be
installed, it must occupy this position.
2. Fasten the four mounting screws with grommets into the sides of the 2.5-inch drive adapter.
Figure 2-46 Securing the mounting screws into the 2.5-inch drive adapter
42 Chapter 2 Hardware repair and upgrade
