HP ProOne 600 User Manual

Installing a hard disc drive
●
Installing a 3.5-inch hard disc drive
●
Installing 2.5-inch hard disc drives
Installing a 3.5-inch hard disc drive
1. Screw the four mounting screws into the 3.5-inch hard disc drive. Be sure to keep the blue rubber
grommets behind each screw.
Figure 2-42 Inserting the mounting screws
2. With the 3.5-inch hard disc drive connectors facing toward the center of the chassis, place the
hard disc drive cage into the chassis and slide it toward the center until it snaps into place.
Figure 2-43 Inserting the 3.5-inch hard disc drive into the cage
40 Chapter 2 Hardware repair and upgrade
