Fabric OS Troubleshooting and Diagnostics Guide 87
53-1002150-02
Switch status
10
Faulty ports monitor HEALTHY
Missing SFPs monitor HEALTHY
All ports are healthy
For more information on how the overall switch status is determined, refer to the
switchStatusPolicySet command in the Fabric OS Command Reference.
Displaying switch information
Table 15 lists the switch summary information
The following additional properties are displayed in the switch summary for Virtual Fabrics-enabled
switches.
TABLE 15 Switch summary information
Variable Definition
switchType Switch model and revision numbers
switchName Switch name
switchState Switch state: Online, Offline, Testing, or Faulty
switchMode Switch operation mode: Native, Interop, or Access Gateway
switchRole Principal, Subordinate, or Disabled
switchDomain ID: 0-31 or 1-23
switchId Switch embedded port D_ID
switchWwn Switch World Wide Name (WWN)
switchBeacon Switch beaconing state: On or Off
zoning When Access Gateway mode disabled, the name of the active zone displays
in parenthesis.
FC Router FC Router’s state: On or Off
FC Router BB Fabric ID The backbone fabric ID for FC routing
TABLE 16 VF output values
Variable Definition
LS Attributes Displays logical switch attributes, including the fabric ID (FID) associated with
the logical switch and the switch role (default switch or base switch).
Allow XISL Use Allows the switch to use extended interswitch links (XISL) in the base fabric
to carry traffic to this logical switch. Values are ON or OFF.
