108 Fabric OS Troubleshooting and Diagnostics Guide
53-1002150-02
Switch Type and Blade ID
A
You can use Table 23 to find the description of the blade model displayed in the output from the
slotShow command.
switch:admin> slotshow
Slot Blade Type ID Model Name Status
--------------------------------------------------
1 SW BLADE 77 FC8-64 ENABLED
2 AP BLADE 75 FX8-24 ENABLED
3 AP BLADE 33 FA4-18 ENABLED
4 SW BLADE 39 FC10-6 ENABLED
5 CORE BLADE 52 CORE8 ENABLED
6 CP BLADE 50 CP8 ENABLED
7 CP BLADE 50 CP8 ENABLED
8 CORE BLADE 52 CORE8 ENABLED
9 AP BLADE 43 FS8-18 ENABLED
10 SW BLADE 37 FC8-16 ENABLED
11 SW BLADE 55 FC8-32 ENABLED
12 AP BLADE 75 FX8-24 ENABLED
67 Brocade Encryption Switch Condor2 8 Gb 16-port encryption switch
69 5410 GoldenEye2 8 Gb 12-port embedded switch
71 300 GoldenEye2 8 Gb 16-port switch
72 5480 GoldenEye2 8 Gb 24-port embedded switch
75 M5424 GoldenEye2 8 Gb 24-port embedded switch
76 8000 Condor2 8 Gb 16-FC port, 10 GbE 8-Ethernet port switch
77 Brocade DCX-4S Condor2 8 Gb 192-port core fabric backbone
83 7800 Condor2 8 Gb 16-FC ports, 6 GbE ports extension switch
TABLE 23 B-series blade model descriptions
Blade ID B-series blade model ASIC Description
4 FC2-16 n/a 2 Gb 16-FC ports blade
24 FR4-18i Condor 16 FC-ports with 2 GbE ports router blade
39 FC10-6 Condor 10 Gb 6-FC ports blade
51 FC8-48 Condor2 8 Gb 48-FC ports blade
55 FC8-32 n/a 8 Gb 32-FC ports blade
68 FS8-18 Condor2 8 Gb 16-port encryption blade
74 FC OE10-24 Con dor 2
24-FC ports on an application blade that provides
Converged Enhanced Ethernet to bridge a Fibre
Channel and Ethernet SAN.
75 FX8-24 Condor2 24-FC port with 10 1-GbE and two 10-GbE ports
Fibre Channel routing and FCIP blade
77 FC8-64 Condor2 8 Gb 64-FC ports blade
TABLE 22 switchType to B-Series model converter (Continued)
switchType B-Series switch model ASIC Base switch speed
