HP TOUCHSMART 9100 Maintenance And Service Guide

10.
If the computer includes a game console cover, press the side tab and remove the game console
cover.
11. Remove the 13 screws that secure the back cover to the computer, as follows:
●
three under each side panel
●
three in the I/O connector area
●
two at the bottom of the back cover
●
two near the optical drive
●
three below the black mesh cover toward the bottom
12. Lift the back cover off the computer.
To install the back cover, reverse the removal procedures.
When installing the back cover, note that the back cover has several tabs at the top of the cover that fit
into slots in the top inside of the computer.
Bluetooth module
1. Prepare the computer for disassembly (see Preparing to disassemble the HP TouchSmart PC
on page 12).
2.
Place the computer face down on a soft, flat surface.
3. Remove the hard drive/memory cover (see
Hard drive/memory cover on page 14).
4.
Remove the stand (see
Stand on page 17).
5. Remove the I/O cover (see
I/O cover on page 15).
6. Remove the feet (see
Feet on page 16).
7. Remove the back cover (see
Back cover on page 22).
24 Chapter 4 Removal and Replacement Procedures

HP TOUCHSMART 9100 Specifications

General

Processor cache	2 MB
Processor cores	2
Processor family	Intel® Core™2 Duo
Processor frequency	2.1 GHz
Processor cache type	L3
Processor manufacturer	Intel
Processor front side bus	800 MHz
Chassis type	All-in-One
Display included	Yes
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Graphics card family	NVIDIA
Floppy drive installed	No
Parallel ports quantity	0
Maximum graphics card memory	- MB
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Number of processors installed	1
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Discrete graphics card model	NVIDIA GeForce 200
Operating system installed	Windows 7 Professional
USB 2.0 ports quantity	5
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Product color	Black
Country of origin	China

Weight and Dimensions

Depth (with stand)	72 mm
Width (with stand)	579 mm
Height (with stand)	447 mm
Weight (with stand)	11500 g
