VTR Emulation RS-422 Control Cables
Custom cables are required to control the VTR emulator. The pinouts required
by the cable depend on the workstation and device involved in the VTR
emulation process. The following diagrams depict the control cable pinouts
required for the most common VTR emulation setups.
1
6
2
7
3
8
4
9
5
1
6
2
7
3
8
4
9
5
WHT
BLK
BLK
RED
GND
2 -RX -
7 -RX +
8 -TX-
3 -TX+
8 -TX-
3 -TX+
2 -RX -
7 -RX+
4 - GND (SHIELD)
4 - GND (SHIELD)
PAIR1
PAIR2
VTR-Emulation Control Cable
Linux(AJA) Master Controlling Linux(AJA) Emulator
Linux(AJA) Master Linux(AJA) Emulator
OEM-2K: MALE DB9
OEM-LH: FEMALE DB9
OEM-2K: MALE DB9
OEM-LH: FEMALE DB9
RS-422
36 | Chapter 4 Setting Up Video Hardware
