Lucid ADA 88192 Converter Settings for Local
Control
You must configure the following settings to control the converter locally.
Any setting not listed here either has no effect with the application or can be
set to any of the values available for it.
CommentMenu ItemMenu
ADAT INs: SRC ONADAT
INs: SMUX OFF
ADAT
AES IN1+2: SRC OFF
AES IN3+4: SRC OFF
AES IN5+6: SRC OFF
AES IN7+8: SRC OFF
AES
IN1+2: SoftClip ON
IN3+4: SoftClip ON
IN5+6: SoftClip ON
IN7+8: SoftClip ON
Analog
Analog INs:
SoftClip
set each input channel to
a value in the range -95.5
to +31.5 dB
Analog
Analog INs: Gain
set either -10 or +4 for
each output channel
Analog
Analog OUTs: Level
3 is the recommended settingClip Detect: 3Meter
If these options do not appear, verify
that Route Unit (in the System, Mis-
cellany menu) is set to 8.
For analog audio:
AES INs --> ADAT OUTs
Analog INs --> AES OUTs
AES INs --> Analog OUTs
Route
For digital audio:
AES INs --> ADAT OUTs
AES INs --> AES OUTs
AES INs --> ANALOG
OUT
External AES 1+2 is the recommen-
ded setting.
Internal OFF
External AES 1+2
Sync
Lucid ADA 88192 Converter Settings for Local Control | 45
