HP xw9400 User Manual

Device Bus# Dev# Fn#
MCP55Pro SMBUS 0 1 1
MCP55Pro Trim 0 1 2
MCP55Pro ASF SMU 0 1 3
MCP55Pro USB OHCI 0 2 0
MCP55Pro USB EHCI 0 2 1
MCP55Pro IDE 0 4 0
MCP55Pro SATA0 0 5 0
MCP55Pro SATA1 0 5 1
MCP55Pro SATA2 0 5 2
MCP55Pro P2P Bridge (Bridge to Slot 3) 0 6 0
MCP55Pro High Definition Audio Controller 0 6 1
MCP55Pro LOM 0 0 8 0
MCP55Pro LOM 1 0 9 0
MCP55Pro PCIE Root Port 0 (Port to Slot 2) 0 F 0
MCP55Pro PCIE Root Port 2 (Port to NEC Bridge) 0 D 0
MCP55Pro PCIE Root Port 5 (Port to Slot 1) 0 A 0
IO55 HT Config 40h 0 0
IOP55 LPC 40h 1 0
IOP55 SMBUS 40h 1 1
IOP55 Trim 40h 1 2
IO55 PCIE Root Port 0 (Port to Slot 5) 40h F 0
IO55 PCIE Root Port 2 (Port to SAS) 40h D 0
IO55 PCIE Root Port 5( Port to Slot 4) 40h A 0
Slot 1 (PCIEx8) 5h 0 0
Slot 2 (PCIEx16) 18h 0 0
Slot 3 (32 bit PCI ) 1h 4 0
Slot 4 (PCIEx8) 45h 0 0
Slot 5 (PCIEx16) 58h 0 0
Slot 6 (PCIX 100) 2Ch 4 0
Slot 7 (PCIX 100/133) 2Ch 9 0
1394 Controller 1h 5 0
NEC PCIX Bridge Controller 2Bh 0 0
NEC PCIX Bridge Controller (No Physical Slot Connections) 2Bh 0 1
LSI SAS Controller 6Bh 0 0
Table I-1 PCI device list (continued)
ENWW PCI bus layout and device list 201
