HP Z210 User Manual

Solving display problems
Table 6-4 Display problems
Problem Cause Solution
Blank screen (no video). The cable connections are not
correct.
Verify the cable connections from the monitor to the
computer and to a working electrical outlet.
The monitor is off. Turn the monitor on (LED is on). You might need to refer to
the monitor manual for an explanation of LED signals.
Screen blanking utility installed
or energy saver features
enabled.
Press a key or the mouse button and, if set, enter your
password.
System ROM is bad; system is
running in FailSafe Boot Block
mode (indicated by 8 beeps).
Reflash the ROM using a SoftPaq.
Fixed-sync monitor does not
sync at the resolution
specified.
Verify that the monitor can accept the same horizontal
scan rate as the resolution specified.
Computer is in Hibernate
mode.
Press the power button to resume from Hibernate mode.
Workstation monitor settings
are not compatible with the
monitor.
1. When you see Press F8 in the bottom-right corner of
the screen, restart the computer and press F8 during
startup.
2. Using the keyboard arrow keys, select Enable VGA
Mode and then press Enter.
3. For Windows, double-click the Display icon in the
Control Panel and then select the Settings tab.
4. Use the sliding control to reset the resolution.
The display works properly during
the POST but goes blank when the
operating system starts.
The display settings in the
operating system are
incompatible with your
graphics card and monitor.
1. For Windows, restart your computer in VGA mode.
2. After the operating system starts, change the display
settings to match those supported by your graphics
card and monitor.
3. Refer to your operating system and graphics card
documentation for information about changing
display settings.
Power LED flashes red 6 times
(once every second), followed by a
2–second pause, and then the
computer beeps 6 times.
Prevideo graphics error. For systems with a graphics card:
1. Reseat the graphics card.
2. If the card requires external power, make sure the
power cable is properly connected.
3. Replace the graphics card.
4. Replace the system board.
Monitor does not function when
used with Energy Saver features.
Monitor without Energy Saver
capabilities is being used with
Energy Saver features
enabled.
Disable the monitor Energy Saver feature.
ENWW
Troubleshooting scenarios and solutions
123

HP Z210 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	6 MB
Processor cores	4
Processor model	E3-1225
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor codename	Sandy Bridge
Processor frequency	3.1 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	31
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Graphics card	Quadro 600
Dimensions (WxDxH)	100 x 381 x 338 mm
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	NVIDIA
Maximum internal memory	16384 MB
Graphics card manufacturer	Nvidia
Audio system	ALC261
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1333 MHz
Memory layout (slots x size)	- GB
HDD speed	- RPM
RAID levels	0, 1
HDD capacity	500 GB
SSD capacity	160 GB
HDD interface	SATA II
SSD interface	SATA
Optical drive type	DVD-RW
Total HDDs capacity	1000 GB
Card reader integrated	-
Number of HDDs installed	2
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
USB 2.0 ports quantity	14
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Chassis type	SFF
Product color	Black
Country of origin	China
Compatible operating systems	Windows 7
Power supply	240 W
Certification	ENERGY STAR 5.0
Processor code	SR00G
Processor ARK ID	52270
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	381 mm
Width	100 mm
Height	338 mm
Weight	7600 g
