Setting up Novell SLED
The workstation can be ordered with Novell SLED preloaded.
HP offers an HP Installer Kit for Linux (HPIKL) to help HP Linux customers customize their system image.
The HPIKL contains the HP driver CD and device drivers to successfully set up the SUSE Linux Enterprise
Desktop (SLED) operating system. The HP Installer Kit for Linux CDs are currently available for
download at
http://www.hp.com/support/workstation_swdrivers.
Setting up SLED on preloaded systems
To set up the SUSE Linux Enterprise Desktop (SLED) on systems preloaded with the operating system:
1. Boot the workstation.
2. Start the Installation Settings and enter the password, network, graphics, time, keyboard settings,
and Novell Customer Center Configuration for the workstation.
NOTE: During Installation Settings the Novell subscription can be activated from the Novell
Customer Center Configuration screen. Visit the full Novell Customer Center documentation at
http://www.novell.com/documentation/ncc/.
Installing from SLED optical media
To install SLED on your workstation, follow this boot procedure prior to installing from the SLED media:
1. With the SLED install media in the DVD drive, restart the workstation and press the F9 key within
three seconds to display the boot menu. If you miss the boot menu, press Ctrl-Alt-Del to restart
and wait slightly more or less before pressing F9.
2. From the list of available boot sources, under Legacy boot sources, pick the optical drive that
contains the SLED install media.
NOTE: Be sure to pick from the list labeled Legacy boot sources when selecting the optical
drive from which to boot. Do not select from UEFI boot sources. Doing so may result in the OS
installation being unable to complete.
3. Press Enter to continue with system boot and the OS installation process.
Installing with the HP driver CD
For instructions on installing the HP driver CD, see “Installing with the HP Installer Kit for Linux” in the
HP Workstations for Linux User Guide at
http://www.hp.com/support/linux_user_manual.
ENWW
Setting up Novell SLED
19

HP Z210 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	6 MB
Processor cores	4
Processor model	E3-1225
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor codename	Sandy Bridge
Processor frequency	3.1 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	31
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Graphics card	Quadro 600
Dimensions (WxDxH)	100 x 381 x 338 mm
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	NVIDIA
Maximum internal memory	16384 MB
Graphics card manufacturer	Nvidia
Audio system	ALC261
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1333 MHz
Memory layout (slots x size)	- GB
HDD speed	- RPM
RAID levels	0, 1
HDD capacity	500 GB
SSD capacity	160 GB
HDD interface	SATA II
SSD interface	SATA
Optical drive type	DVD-RW
Total HDDs capacity	1000 GB
Card reader integrated	-
Number of HDDs installed	2
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
USB 2.0 ports quantity	14
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Chassis type	SFF
Product color	Black
Country of origin	China
Compatible operating systems	Windows 7
Power supply	240 W
Certification	ENERGY STAR 5.0
Processor code	SR00G
Processor ARK ID	52270
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	381 mm
Width	100 mm
Height	338 mm
Weight	7600 g
