HP Z210 User Manual

NOTE: Do not intermix non-ECC memory DIMMs with ECC memory DIMMs.
Graphics
The workstation supports discrete PCIe Gen2 graphics cards in its PCIe2 x16 and PCIe2 x16(4) slots.
The system supports multiple graphics cards as long as the total power usage of these cards fits within
the total graphics power budget of 150W.
To view supported graphic card configurations using HP QuickSpecs, visit
http://www.hp.com/go/
quickspecs, select your geographic region, click on "Workstations," then select your workstation model.
Some workstation models (depending on installed processor type) also support up to two displays with
integrated Intel HD graphics. Most supported Intel Core processors provide Intel HD Graphics 2000.
Intel Xeon processors with model designations that end in "---5" provide Intel HD Graphics P3000. In
Windows 7, you can view the model of CPU installed in the workstation by selecting Start > Control
Panel > System.
NOTE: Intermixing integrated Intel HD graphics and discrete graphics cards in order to drive more
than two displays can be enabled using the Computer (F10) Setup Utility. However, HP recommends
using only discrete graphics cards when attaching three or more displays. To see graphics card
configurations that have been fully tested and validated by HP for use in this workstation, refer to
http://www.hp.com/go/quickspecs.
Expansion card slots
The workstation provides multiple high-performance graphics and I/O slots: one full x16 PCIe2; one
x16(4) PCIe2, one x8(4) PCIe2; two x1 PCIe2; and two PCI 32b/33Mhz slots. These slots provide
extra I/O bandwidth for high speed I/O cards.
Additional features
The workstation provides these additional features:
●
Nine external and three internal USB 2.0 ports.
●
A 400W power supply that is 90% efficient and permits Energy Star Version 5.0 system
configurations.
●
HP WattSaver technology permits support of the European Union ERP Lot 6 tier 2 power limit of
0.5W in off mode.
●
HP Quiet Fan Technology permits quiet system operation.
●
Parallel and serial headers that can be used with an optional PCI bulkhead connector.
ENWW
Product features
3

HP Z210 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	6 MB
Processor cores	4
Processor model	E3-1225
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor codename	Sandy Bridge
Processor frequency	3.1 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	31
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Graphics card	Quadro 600
Dimensions (WxDxH)	100 x 381 x 338 mm
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	NVIDIA
Maximum internal memory	16384 MB
Graphics card manufacturer	Nvidia
Audio system	ALC261
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1333 MHz
Memory layout (slots x size)	- GB
HDD speed	- RPM
RAID levels	0, 1
HDD capacity	500 GB
SSD capacity	160 GB
HDD interface	SATA II
SSD interface	SATA
Optical drive type	DVD-RW
Total HDDs capacity	1000 GB
Card reader integrated	-
Number of HDDs installed	2
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
USB 2.0 ports quantity	14
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Chassis type	SFF
Product color	Black
Country of origin	China
Compatible operating systems	Windows 7
Power supply	240 W
Certification	ENERGY STAR 5.0
Processor code	SR00G
Processor ARK ID	52270
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	381 mm
Width	100 mm
Height	338 mm
Weight	7600 g
