HP Z210 User Manual

Product support
Table D-2 Product support
Topic Location
Additional information For online access to technical support information and
tools, see
http://www.hp.com/go/workstationsupport.
Support resources include Web-based troubleshooting
tools, technical knowledge databases, driver and patch
downloads, online communities, and proactive notification
services.
The following communication and diagnostic tools are also
available:
●
Instant Chat
●
Instant Support
●
Diagnose Problem
Refer to the workstation Maintenance and Service Guide
for more information on how to receive support.
Technical support Before you call technical support, refer to the workstation
Maintenance and Service Guide for a listing of information
you need to have available before you call.
For a listing of all worldwide technical support phone
numbers, see
http://www.hp.com/support/, select your
region, and click Contact HP in the upper-left corner.
HP Support Assistant HP Support Assistant is an HP application that helps you
maintain the performance of your workstation and resolve
problems through automated updates and tune-ups, built-in
diagnostics, and guided assistance.
To access HP Support Assistant, double-click the HP
Support Assistant icon on your desktop.
NOTE: HP Support Assistant is pre-installed on all HP
workstations with Microsoft Windows 7 operating systems.
HP Support Assistant is not available on workstations
running Linux.
Business Support Center (BSC) For software/driver downloads, warranty information,
single-topic documents, user manuals, or service manuals,
see
http://www.hp.com/go/bizsupport.
IT Resource Center (ITRC) See
http://www.itrc.hp.com/ for a searchable knowledge
base for IT professionals.
HP Business and IT Services. For business and IT information, see
http://www.hp.com/
hps/.
ENWW
Product support
167

HP Z210 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	6 MB
Processor cores	4
Processor model	E3-1225
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor codename	Sandy Bridge
Processor frequency	3.1 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	31
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Graphics card	Quadro 600
Dimensions (WxDxH)	100 x 381 x 338 mm
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	NVIDIA
Maximum internal memory	16384 MB
Graphics card manufacturer	Nvidia
Audio system	ALC261
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1333 MHz
Memory layout (slots x size)	- GB
HDD speed	- RPM
RAID levels	0, 1
HDD capacity	500 GB
SSD capacity	160 GB
HDD interface	SATA II
SSD interface	SATA
Optical drive type	DVD-RW
Total HDDs capacity	1000 GB
Card reader integrated	-
Number of HDDs installed	2
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
USB 2.0 ports quantity	14
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Chassis type	SFF
Product color	Black
Country of origin	China
Compatible operating systems	Windows 7
Power supply	240 W
Certification	ENERGY STAR 5.0
Processor code	SR00G
Processor ARK ID	52270
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	381 mm
Width	100 mm
Height	338 mm
Weight	7600 g
