Huawei UPS2000-A Series User Manual

UPS2000-A-(6 kVA-10 kVA)
User Manual
2 Overview
Issue 05 (2019-12-19)
Copyright © Huawei Technologies Co., Ltd.
23
2.4 Optional Components
Table 2-2 Optional components
Component
Model
Function
Remarks
Parallel cable
N/A
Connect UPSs in
parallel.
DB15
male-CC8P0.48
black (S)-DB15
female, 1.5 m
Cable between
the UPS and
battery packs
N/A
Connect a UPS with
long backup time and
battery packs. This
cable is optional for a
UPS with long backup
time and is not required
for a UPS with standard
backup time.
1.5 m, one end
are PP45
terminals
(connected to the
battery pack),
and the other end
are OT terminals
(connected to the
UPS).
Ambient
temperature
and humidity
sensor
ENR1DETA Sensor
The ambient
temperature ranges
from 0–50ºC. The
ambient humidity
ranges from to
0%–100% RH.
It is used
together with a
Simple Network
Management
Protocol (SNMP)
card. The cable is
delivered with
the SNMP card
by default and is
1.5 m long.
SNMP card
RMS-SNMP01A
Monitors the UPS and
provides the Ethernet
networking solution. It
can also monitor
ambient temperatures
and humidity.
The
communication
ports of the
SNMP card
include an
Ethernet port and
a USB port (used
for connecting a
GSM modem,
which is a
Huawei product).
A temperature
and humidity
sensor is
optional. The
SNMP card can
also be used for
web monitoring.
It can be
accessed through
Internet Explorer
and applies to
large-scale and
