UPS2000-A-(6 kVA-10 kVA)
User Manual
Copyright © Huawei Technologies Co., Ltd.
4. Remove the bolt, spring washer, and flat washer.
Step 5 Secure the UPS to the ground using M12x60 expansion bolts, as shown in Figure 3-10.
Figure 3-10 Securing a UPS
----End
3.2.3 Connecting Cables
Connect UPS AC input and output terminals L, N correctly. For a UPS with long backup
time, connect the battery terminals correctly.
Before connecting cables, ensure that the input and output circuit breakers are OFF. For a
UPS with long backup time, ensure that the battery circuit breakers are OFF. Perform all
tasks with the power off.
3.2.3.1 Connecting Cables to the UPS Standard Version with Standard
Backup Time
Procedure
Step 1 Switch off the AC input circuit breaker at the rear of the UPS and the upstream AC circuit
breaker of the UPS.
Step 2 Remove the UPS input and output wiring cover.
