UPS2000-A-(6 kVA-10 kVA)
User Manual
Copyright © Huawei Technologies Co., Ltd.
4.5.1 Starting the UPS in Normal Mode
After the UPS is powered on, the LCD screen lights up for 1 second, and then initialization
starts. After the progress bar is complete, the default screen is displayed, as shown in Figure
4-3.
Figure 4-3 Power-on and default screen
Press for 5 seconds. Release the button when you hear a beep sound. The startup screen
is displayed. After the UPS starts successfully, it enters normal mode, as shown in Figure 4-4.
Figure 4-4 Normal mode
4.5.2 Starting the UPS in Battery Mode
After the UPS is powered on, press . Then, the LCD screen lights up. After the screen
lights up for 1 second, initialization starts. After the initialization progress is complete, the
default screen is displayed, as shown in Figure 4-5.
