English - 49
3. INSTALLATION
If the guide wire is to be used for the
Follow loop out
function:
• If the guide wire runs on the right, seen in the
mower's direction of entry, the guide wire must
be routed at least 130 cm (4 ft) straight out from
the front edge of the charging plate. In this
instance, Automower
®
will find the right loop
signal strength without problem and follow the
guide wire.
• If the guide wire runs on the left, seen in the
mower's direction of entry, the guide wire must
be routed at least 2 m (6.5 ft) from the front edge
of the charging plate. In this instance,
Automower
®
will find it difficult to find the low loop
signal strengths, i.e. if a high Corridor width
value is used. There is then a risk that the mower
will not find the right strength on the loop signal
and can not follow the guide wire.
If the guide wire is to be used for the
Follow loop in
function:
• When the guide wire is only used for the
Follow
loop in
function it is sufficient for the guide wire to
be routed 70 cm (2.5 ft) straight out from the front
edge of the plate.
• Should the mower, when it follows the guide
wire, collide with an obstacle, it changes direction
and leaves the guide wire.
The standard boundary wire should be used for the
guide wire. Use a regular boundary wire as a guide
wire. There are three varieties, 150 m (480 ft) (501 98
03-01), 250 m (800 ft) (501 98 03-02) or 500 m (1600)
(522 91 41-01, extra strong).
The guide wire should be connected to the boundary
wire with the help of an original connector,
501 98 02-01. See the picture opposite.
130 cm (4 ft)
2 m (6.5 ft)
