Learn your Quilt Designer II
6
3. 1.
2.
Pack Away After Sewing
1. Press the power switch to turn off the machine.
2. Unplug the cord from the wall socket fi rst and
then from the machine.
3. Wind the main cord around your hand and place
the cord in the pocket of the hard cover. Here you
can also place the User’s Gui de.
4. Unplug the foot control cord from the machine.
Wind the foot control cord around your hand and
place it in the space of the foot control.
5. Check to ensure that all accessories are in the
accessory tray. Slide the tray on to the machine
aro und the free arm.
6. Place the foot control, with the underside towards
you, fi tting into the recess of the accessory tray at
the rear side of the machine.
Connect to the Power Supply
Among the accessories you fi nd the main cord.
On the underside of the machine you will fi nd
information about the power supply (V) and the
frequency (Hz).
Before plugging in, check to ensure that the foot
control is of “type FR4” (see underside of foot
control).
1. Take out the cord from the foot control. Connect
the foot control cord to the front socket on the
bottom right side of the machine.
2. Connect the main cord to the rear socket on the
bot tom right side of the machine.
3. When you press the power switch to ON, both the
machine and the lights are switched on.
For the USA and Canada
This Sewing Machine has a polarized plug (one
blade wider than the other). To reduce the risk
of electric shock, this plug is intended to fi t in a
polarized outlet only one way. If the plug does not
fi t fully in the outlet, reverse the plug. If it still does
not fi t, contact a qualifi ed electrician to install the
proper outlet. Do not modify the plug in any way.
