Item Part No. Qty Name
1 794446 1 CS .625-11X1.500HXG5
2 028118 4 FW 0.625X1.00X.13 ZN
3 603057 3 DUST SHIELD W/OFFSET
4 781856 1 PULLEY, IDLER NHI 5.00"
5 600296 2 SPACER, DECK IDLER
6 350884 1 SLIDE, DECK IDLER
7 781302 1 IDLER SPRING
8 259812 1 CHAIN, 13 LINK
9 603023 4 WN .312-18 ZN
10 602936 2 IDLER SLIDE, UHMW
11 016972 2 NT .625-11 HX G5 ZN
12 781385 2 PULLEY, IDLER NHI 6.00"
13 113340 1 PUSHER W/A, HZ/SZ
14 015495 2 GREASE FITTING STRAIGHT
15 767954 6 FW 0.379X.82X.06 HD ZN
16 086660 6 NT .375-16NLG8
17 705954 15 CS .500-13X1.25 HX G5 ZN
18 752386 3 CW .515X 2.25X .204 BLK
19 602842 3 PULLEY, DRIVE 5.187 OP
20 045765 3 FW 1.030X1.50X.13 HD ZN
21 767962 15 FW .531 x 1.063 x .175
22 212472 3 KEY 1/4 SQ X 1.00 LG(FS)
23 607407 3 SPINDLE ASSY, DUCTILE
Not Shown 601630 3 SPINDLE ASSY, 3" PILOT
Comments for Part Num. 601630
Spindle has no service parts available. Replace complete spindle assembly.
24 603022 4 CS .312-18X.625 BH ZN
25 782474 2 CW .678 X 2.250 X .187
26 783738 2 CS .625-11X3.000HXG5
27 603113 6 CB .375-16X1.250 G5 ZN
28 602338 1 CB .50-13 X 7.50 STD ZN
29 602344 1 SPACER, ANTI- SCALP 5.73
30 602341 1 WHEEL, ANTI-SCALP
31 781567 3 NT .500-13NLG5
32 602263 2 WHEEL, ANTI-SCALP
48" Side Discharge - Deck Pulleys & Spindles Hustler X-ONE Parts Manual
Tue May 19 17:15:32 UTC 2020 8.1-2
