Comments for Page: Seat, Standard - S/N 11020000 & HIGHER
1. Do not torque; the seat pan & seat pan stop must pivot freely.
2. 550741 includes decals and installation kit.
Item Part No. Qty Name
1 602967 1 SEAT, STANDARD
2 113393 1 SEAT LATCH W/A, HZ
3 783910 1 SPRING, TORSION
4 768523 5 FW 0.343SAE
5 601815 1 DECAL, BATTERY WARNINGS
6 767954 13 FW 0.379X.82X.06 HD ZN
7 086660 4 NT .375-16NLG8
8 058776 5 NT .312-18NLG5
9 754358 1 SB0.375X0.375SH0.312-18
10 000331 2 WIRE TIE, SMALL/SHORT
11 550741 1 SEAT PAN, SERVICE
12 785188 1 DECAL, Z ARMREST WARNING
13 712927 4 FW 0.344X1.00X.12 HD ZN
14 350421 1 SEAT PAN STOP (PLATED)
15 036244 5 CS .375-16X1.00 HX G5 ZN
16 724716 1 WASHER, FIBER (FS)
17 791848 1 DECAL, FUEL INDICATOR- M
18 601968 1 DECAL, HYDRAULIC PRESS
19 601650 2 VIBRATION MOUNT 70DURO
20 550742 1 SEAT SUPPORT, SERVICE
21 601967 1 DECAL, ENGINE COMPART
22 550766 1 FRAME COVER LS, SERVICE
23 600899 1 DECAL, PUMP BELT WARNING
24 601069 5 CN .312-18x.200 MAX THK
25 785139 1 DECAL, STEERING L.S.
26 779280 1 DECAL, HOT & HYD OIL
27 054502 2 NT .375-16HXG5
28 550765 1 FRAME COVER RS, SERVICE
29 785220 1 DECAL, STEERING R.S.
30 036236 5 CS .312-18X1.000HXG5
31 052860 2 CS .375-16X1.25 HX G5 ZN
Seat, Standard - S/N 11020000 & HIGHER Hustler X-ONE Parts Manual
Tue May 19 17:15:58 UTC 2020 9.1-2
