Comments for Page: Brake
1. Included with the wheel motor.
2. Torque to 220-240 ft-lbs.
3. Torque to 27 ft-lbs.
4. The hub assembly includes the studs. 606124 wheel studs are used on mowers S/N higher than 12022668.
601085 wheel studs are used on mowers S/N prior to 12022668.
Item Part No. Qty Name
1 086660 2 NT .375-16NLG8
2 767954 12 FW 0.379X.82X.06 HD ZN
3 765339 4 BUSHING,IGUS#0608 (FS)
4 023655 4 NT 0.312-24 NL G8
5 768523 12 FW 0.343SAE
6 781583 2 BRAKE ROD ASSEMBLY
7 113215 1 BRAKE BELLCRANK, RS
8 113216 1 BRAKE BELLCRANK, LS
9 054502 4 NT .375-16HXG5
10 080655 2 CS .375-16X1.500HXG5
11 052514 2 CS .375-16X4.500HXG5
12 350397 2 BRAKE LINK TURNBUCKLE A
13 034272 4 NT .312-18HXG5
14 602383 2 BRAKE ASSY, PARKER
15 602384 2 HUB ASSY, PARKER
16 111309 2 BRAKE ARM,Z4
17 604461 8 CS .312-18X.75HXG8 FL
18 005116 2 CS .375-16X1.38 HX G5 ZN
19 037887 4 CB .312-18X 1.000 FUL ZN
20 606124 5 STUD 1/2-20 X 1 1/2"
Not Shown 601085 1 STUD, WHEEL LUG 1/2-20
Brake Hustler X-ONE Parts Manual
Tue May 19 17:14:42 UTC 2020 4-8
