1. Torque all hardware to 33 ft-lbs ± 10%.
Item Part No. Qty Name
1 NSS 1 STEERING ARM W/A
2 086660 3 NT .375-16NLG8
3 767954 6 FW 0.379X.82X.06 HD ZN
4 705178 3 CS .375-16X1.750HXG5
5 112899 1 STEERING BOX W/A LH
Not Shown 112898 1 STEERING BOX W/A, RH
6 781153 2 BUSHING, UHMW
7 348862 2 STEERLEVER BUSHING (PLA
8 047456 1 GM .750X.188X1.00X.12
9 797738 1 SS .500-13X2.000SH
Steering Box Breakdown Hustler X-ONE Parts Manual
Tue May 19 17:14:41 UTC 2020 4-7
