Comments for Page: Fuel System without Carbon Canister - S/N 13020642 & HIGHER
1. Torque to 20 ft-lbs.
A: 29" vapor line from the right tank to the vapor tee
B: 19" fuel line from the right tank to the fuel valve
C: 40" fuel line from the left tank to the fuel valve
D: 21" vapor line from the left tank to the vacuum breaker
E: 8" vapor line from the vapor tee to the vacuum breaker
Item Part No. Qty Name
1 605107 1 TANK, FENDER, R.H.
2 605108 1 TANK, FENDER, L.H.
3 603807 2 CAP, 3.5" RATCHETING GAS
4 000323 4 CLIP, HOSE CLAMP
5 015818 59" FUEL LINE, 1/4"
Comments for Part Num. 015818
Sold by the foot.
6 745059 1 FUEL VALVE 3-WAY
7 604281 1 TEE, 3/16" PLASTIC
8 604305 1 VACUUM BREAKER
9 712919 10 FW 0.406X1.00X.12 HD ZN
10 055822 10 CS .375-16X0.75 HX G5 ZN
11 036236 3 CS .312-18X1.000HXG5
12 768523 6 FW 0.343SAE
13 043570 3 CLIP - HOSE - SINGLE(FS)
14 034272 3 NT .312-18HXG5
15 116229 1 COVER, REAR
16 055947 4 CS .250-20X0.50 HX G5 ZN
17 768515 4 FW 0.281SAE
18 116228 1 COVER, FRONT
19 603326 58" VAPOR LINE, 3/16"
Comments for Part Num. 603326
Sold by the foot.
Fuel System without Carbon Canister - S/N 13020642 & HIGHER
Hustler X-ONE Parts Manual
Tue May 19 17:15:04 UTC 2020 6.2-4
