Item Part No. Qty Name
1 794446 1 CS .625-11X1.500HXG5
2 028118 7 FW 0.625X1.00X.13 ZN
3 796714 5 PULLEY, 6" HB IDLER RD
4 600296 1 SPACER, DECK IDLER
5 109948 1 IDLER ARM W/A
6 781567 1 NT .500-13NLG5
7 767962 13 FW .531 x 1.063 x .175
8 770867 2 BUSHING, PLAS .750x1(FS)
9 109549 1 BUSHING, IDLER PIVOT
10 781302 1 IDLER SPRING
11 259812 1 CHAIN, 13 LINK
12 016972 4 NT .625-11 HX G5 ZN
13 704759 1 FW 0.500X1.25X.08 ZN
14 797910 2 CS .312-18x1.50FLT SH ZN
15 601779 1 IDLER GUIDE, UHMW
16 782474 2 CW .678 X 2.250 X .187
17 783738 2 CS .625-11X3.000HXG5
18 768523 1 FW 0.343SAE
19 058776 1 NT .312-18NLG5
20 016527 3 CS .500-13X1.000HXG5
21 752386 3 CW .515X 2.25X .204 BLK
22 798967 3 PULLEY, B-SEC 5.44 EOD
23 212472 3 KEY 1/4 SQ X 1.00 LG(FS)
24 705954 12 CS .500-13X1.25 HX G5 ZN
25 607407 2 SPINDLE ASSY, DUCTILE
26 607408 1 SPINDLE ASSY, DUCTILE
54" Rear Discharge - Deck Pulleys & Spindles Hustler X-ONE Parts Manual
Tue May 19 17:15:41 UTC 2020 8.3-2
