Comments for Page: Fuel System without Carbon Canister - S/N PRIOR TO 12022042
1. Torque to 20 ft-lbs.
A: 28" vapor line from the right tank to the vapor tee
B: 12" fuel line from the right tank to the fuel valve
C: 31" fuel line from the left tank to the fuel valve
D: 22" vapor line from the left tank to the vacuum breaker
E: 8" vapor line from the vapor tee to the vacuum breaker
Item Part No. Qty Name
1 606600 1 TANK, FENDER RH
2 606599 1 TANK, FENDER LH
3 602916 2 CAP, 3.5" RATCHETING GAS
4 000323 12 CLIP, HOSE CLAMP
5 015818 101" FUEL LINE, 1/4"
Comments for Part Num. 015818
Sold by the foot.
6 745059 1 FUEL VALVE 3-WAY
7 603025 1 TEE, 1/4x1/4x3/16
Not Shown 603306 1 TEE, 1/4" PLASTIC
8 603024 1 VACUUM BREAKER
9 712919 10 FW 0.406X1.00X.12 HD ZN
10 055822 10 CS .375-16X0.75 HX G5 ZN
11 036236 3 CS .312-18X1.000HXG5
12 768523 6 FW 0.343SAE
13 043570 3 CLIP - HOSE - SINGLE(FS)
14 034272 3 NT .312-18HXG5
Fuel System without Carbon Canister - S/N PRIOR TO 12022042
Hustler X-ONE Parts Manual
Tue May 19 17:15:06 UTC 2020 6.2-6
