Comments for Page: Pump Drive, Clutch & Drive Belt
1. Torque to 45–48 ft-lbs. Do not reuse the fastener if it is loosened or removed. Replace it with a new fastener. Use only hand tools to install
Item Part No. Qty Name
1 051151 1 CS .500-13X5.000HXG5
2 344267 1 FW .510X2.15X.19 ZN
3 034272 2 NT .312-18HXG5
4 768523 4 FW 0.343SAE
5 113347 1 CLUTCH ANCHOR
6 036236 2 CS .312-18X1.000HXG5
7 212076 1 KEY 1/4 SQ X 1.50 LG(FS)
8 602903 1 PULLEY 6.35 OPx1.125SHFT
9 601311K 1 CLUTCH KIT
10 791251 1 HARNESS, CLUTCH PIGTAIL
Comments for Part Num. 791251
Pigtail was updated with epoxy to hold the wires steady. The wire sheath was also updated to a more flexible material.
11 602680 1 FW .453X1.12X.12 HRD ZN
12 785659 1 CS .437-20X2.50 HXG5 P85
Not Shown 785048 1 CS .437-20X3.00 HXG5 P85
13 602904 2 PULLEY 6.35 OPx0.592SHFT
14 083196 4 SS .312-18X0.750SQ
15 768127 2 KEY 5mm x30mm RADIUS EN
16 602880 1 BUSHING, IDLER PIVOT
17 025007 1 CS .62511X1.750HXG5
18 602304 1 PULLEY, 5" FLAT IDLER
19 113403 1 TENSIONER
20 601016 1 IDLER SPRING
21 601486 1 EB, .375-16X3.00 FULTHD
22 054502 2 NT .375-16HXG5
23 767954 2 FW 0.379X.82X.06 HD ZN
24 015495 1 GREASE FITTING STRAIGHT
25 602879 1 BUSHING, IDLER PIVOT
26 767962 1 FW .531 x 1.063 x .175
27 781567 1 NT .500-13NLG5
28 602907 1 DRIVE BELT
Pump Drive, Clutch & Drive Belt Hustler X-ONE Parts Manual
Tue May 19 17:14:38 UTC 2020 4-4
