Item Part No. Qty Name
1 602966 1 SEAT, SUPER DELUXE
2 113393 1 SEAT LATCH W/A, HZ
3 783910 1 SPRING, TORSION
4 016253 2 CB .312-18X .750 FUL ZN
5 113713 1 SEAT STOP
6 601815 1 DECAL, BATTERY WARNINGS
7 767954 13 FW 0.379X.82X.06 HD ZN
8 086660 4 NT .375-16NLG8
9 768523 7 FW 0.343SAE
10 034272 2 NT .312-18HXG5
11 754358 1 SB0.375X0.375SH0.312-18
12 058776 5 NT .312-18NLG5
13 000331 2 WIRE TIE, SMALL/SHORT
14 550741 1 SEAT PAN, SERVICE
15 785188 1 DECAL, Z ARMREST WARNING
16 712927 4 FW 0.344X1.00X.12 HD ZN
17 724716 1 WASHER, FIBER (FS)
18 350421 1 SEAT PAN STOP (PLATED)
19 036244 5 CS .375-16X1.00 HX G5 ZN
20 601968 1 DECAL, HYDRAULIC PRESS
21 791848 1 DECAL, FUEL INDICATOR- M
22 601650 2 VIBRATION MOUNT 70DURO
23 779280 1 DECAL, HOT & HYD OIL
24 552386 1 SEAT SUPPORT, X1
25 601967 1 DECAL, ENGINE COMPART
26 550766 1 FRAME COVER LS, SERVICE
27 600899 1 DECAL, PUMP BELT WARNING
28 601069 5 CN .312-18x.200 MAX THK
29 054502 2 NT .375-16HXG5
30 785139 1 DECAL, STEERING L.S.
31 550765 1 FRAME COVER RS, SERVICE
32 785220 1 DECAL, STEERING R.S.
33 036236 5 CS .312-18X1.000HXG5
34 052860 2 CS .375-16X1.25 HX G5 ZN
Seat, Super Deluxe Hustler X-ONE Parts Manual
Tue May 19 17:16:00 UTC 2020 9.2-1
