Torch parts
MAINTENANCE AND PARTS
3
5-10 powermax1650 Operator Manual
Parts
059264 T100 hand torch assembly, 25 ft (7.5 m)
059270 T100 hand torch assembly, 50 ft (15 m)
059299 T100 hand torch assembly, 75 ft (22.9 m)
059315 T100M-2 machine torch assembly, 25 ft (7.5 m)
059324 T100M-2 machine torch assembly, 35 ft (10.7 m)
059325 T100M-2 machine torch assembly, 50 ft (15 m)
059326 T100M-2 machine torch assembly, 75 ft (22.9 m)
059333 T100M-2 machine torch, 35 mm (no gear rack), 25 ft (7.5 m)
059334 T100M-2 machine torch, 35 mm (no gear rack), 35 ft (10.7 m)
059335 T100M-2 machine torch, 35 mm (no gear rack), 50 ft (15 m)
059336 T100M-2 machine torch, 35 mm (no gear rack), 75 ft (22.9 m)
027055 Silicone grease, 1/4 oz. tube
015337 Quick disconnect nipple: 1/4 NPT steel (CSA)
015145 Adapter: 1/4 NPT x G1/4 BSPP brass (CE)
058519 Torch o-ring
128644 T100 hand torch handle replacement kit (5 screws included)
075586 T100 hand torch handle screw (5 required)
220061 Shield cap: T60M/T80M ohmic contact
220206 Shield cap: T100M-2 ohmic contact
Technical questions
If you are unable to fix a problem with your Powermax by following the steps in Basic
troubleshooting in this section, or if you need further assistance:
1. Call your Hypertherm distributor or authorized Hypertherm repair facility.
2. Call the nearest Hypertherm Technical Service team listed in the front of this manual.
