10-1
1. ENGINE SYSTEM
10. TESTING AND ADJUSTING
EASE OF STARTING, NOISE
Set gear selector lever at NEUTRAL.
(1)
1)
Put the parking brake switch in LOCK
position.
Turn ON start switch, automatically heat-
ing operated.
When preheater pilot lamp goes out, turn
start switch to START, and start engine.
When engine starts, check if it starts
smoothly, and if it makes any abnormal
noise.
(2)
(3)
(4)
ö
Forward
Backward
Neutral
110D9OM45
Parking
brake switch
Start switch
LOCK
OFF
ON
START
300D9OM10
WHEN ACCELERATOR PEDAL IS DEPRESSED
Check that accelerator pedal does not catch when depressed.
Check that engine speed increases in accordance with amount pedal is depressed.
When doing this, check that engine speed changes without gasping, abnormal noise, abnormal
explosions, or irregular vibration.
Check that exhaust gas is colorless when the engine is idling, and a thin black color when
accelerator pedal is depressed.
Max speed : SEE SECTION 8. SPECIFICATIONS
IDLING
After warming up engine, run at idling.
Check that engine maintains steady,
smooth rotation without gasping,
abnormal noise, abnormal explosions, or
irregular vibration.
Check that idling speed is within specified
range.
Idle rpm : SEE 8. SPECIFICATION
(1)
(2)
(3)
(4)
(1)
(2)
(3)
(4)
(5)
2)
3)
160D7TA01T
Accelerator pedal
