9-32
Maintenance
AIR CLEANER
Filter replacement
The air cleaner filter can be cleaned for
inspection using compressed air.
Do not attempt to wash or to rinse it.
Otherwise, water will damage the filter.
If soiled, the air cleaner filter must be
replaced.
OAI3089040
OAI3089041
1. Loosen the hose clamp and remove
hose from cleaner.
2. Open the cleaner cover by openingthe
clips.
OAH2078017
3. Remove the used filter and wipe
the inside of the air cleaner housing
carefully not to remain dusts incover
housing.
4. Place the new filter with clean hands
and ensure the rubber gasket is not
taken off.
5. Reassemble in the reverse order of
removal.
