IBC EX 700 Installation And Operating Manual

EX 700, EX 850
Intake Pipe Size Maximum Equivalent Length
Sched.40; Rigid PPs
6" PVC/CPVC / Rigid PPs/SS 120' each side
90° vent elbow allow 5' equivalent
45° elbow allow 3' equivalent
PPs 87-90° elbows use 5' equivalent
Table 7 Maximum intake pipe venting length for EX 700, 850
For the inlet air – 6" Schedule 40 PVC, CPVC, ABS, PPs or SS piping of any type is permitted.
Note
Unused intake travel cannot be added to the exhaust. Unequal intake and exhaust piping is
allowed.
Ensure that adequate separation is maintained between the air intake inlet and the vent terminal. Refer to
the vent terminal configuration drawings in the Vent Termination section above.
Use support for intake piping, particularly for horizontal runs (follow local codes).
3.5.9 Indoor air combustion air intake
An “Indoor Combustion Air installation” can be described as air for combustion that is taken from the air
surrounding the boiler.
Warning
When using indoor air options, supply adequate combustion air to the boiler room according to
the requirements of all applicable codes.
35
3.5.9 Indoor air combustion air intake
