Connecting the external cables
__ If you are using any optional adapters (such as token ring or 8-port EIA-232), connect the cables to the
appropriate adapter connectors in the PCI slots of your server.
See Adapters, Devices, and Cable Information for Multiple Bus Systems for a description of cables and adapters
that might be installed on your server.
Note: If the cable did not come with your server, you will have to supply it.
__ Route the cables through the cable-management arm, and secure the cables with the straps that are provided.
After you finish
_ Return to your initial server setup checklist and complete the next step.
Related concepts
Installing features and replacing parts
Related reference
Back view of a model 7037-A50
Related information
Adapters, Devices, and Cable Information for Multiple Bus Systems
Cabling your 7047-185 workstation
For a graphical representation of the slots and connectors, see the back view of the model.
Attention: This product is equipped with a three-wire power cable and plug for user safety. Use this
power cable with a properly grounded electrical outlet to avoid electrical shock.
To cable your system unit:
Before you begin
__ If you have hardware features that are not installed, install them now. For instructions, see Installing features
and replacing parts.
Connecting the power cords
__ Connect the system power supply to a power source.
216 System i and System p: Cabling your server
